Original Maserati Spare Parts For Sale
Parts for cars post-1980

PLEASE BE AWARE: SOME OF THESE PARTS MAY NO LONGER BE AVAILABLE, AND PLEASE BEAR IN MIND THAT SOME PARTS WERE ALREADY IN SHORT SUPPLY, DUE THE FACTORY'S FAILURE TO RESTOCK FOLLOWING CESSATION OF THE TIME LIMIT FOR THEIR STATUTORY OBLIGATION TO SUPPLY SPARE PARTS.

With many parts for the Biturbo-era cars becoming increasingly difficult to get hold of, I thought it would be a good idea to publish a list of what is still available here in the UK.

So you can imagine how delighted I was to receive this reply from Ross Peters at Meridien-Modena to an email I sent him requesting further information on available parts. Just in case you weren't aware, Meridien-Modena have been an official Maserati concessionaire for many years now, and I am grateful to them for their support.

The splendid Meridien Maserati adverts that appeared in magazines during the Nineties


1995
1996
1997
1998

The splendid Meridien Modena adverts that have appeared in magazines in recent years up to today


2000
2004
2005
2008


During the late eighties the then importer Maserati UK Ltd went into receivership. In 1991 John Butt and his team bought the franchise. Meridien Maserati was formed and it was through their efforts that the Marque and its owners were well represented here in the UK.

With the comparative success of the Ghibli, Meridien moved to impressive premises in Bournemouth. When Maserati went under Ferrari control, the role of importer was moved to Maranello Concessionaires.

In May 2000 Meridien-Modena moved back to Lyndhurst when they were made official Ferrari and Maserati dealers for the south coast. Today they have one of the most experienced workshops for today's and 'Biturbo-era' Maseratis in the country.

All UK Maserati owners should be grateful for Meridien's sterling work!

"Hi Enrico,

In response to your request for details of the Maserati parts that we have in stock, please find attached a list of original Maserati spare parts for post-1980 models. I have also included a guide to facilitate part recognition.

Maserati Biturbo parts were originally constructed in the following way; the first 2 digits indicate the model type, the next 2 show its position on the car ( front, back, engine, etc. etc. ), and the last digits are either random or can be used to show it is either left, right, upper or lower, etc. etc.

I only know for sure the first 2 numbers, these indicate the model that Maserati originally designed the part for, but that does not necessarily mean it will only fit that particular model, as many Maserati parts are very interchangeable!

These were the original part no. pre cursers…

30 = Quattroporte III

31 = Biturbo Coupe ( from 2.5 to Racing )

32 = Biturbo 4-door ( 425 to 4.24v )

33 = Spyder/Karif

34 = 228



35 = Not used

36 = Ghibli

37 = Quattroporte IV

38 = 3200 GT

39 = Shamal

When Fiat took over control, they then constructed engine part numbers separately, they are…

479 = V8 Engine

470 = V6 Engine

Then Ferrari took over and made these precursors for engine…

580 = V6 Engine

585 = V8 Engine

As discussed, I am happy to help your website visitors with parts enquires. If we don’t have it, I have access to all the dealers stock in the world and of course the factory, so can point them in the right direction.

Visitors may contact me direct at rosspeters@meridien.co.uk.

Regards,

Ross Peters."

ONCE YOU KNOW THE ORIGINAL PART NUMBER, JUST CHECK THIS LIST FOR AVAILABILITY !!


All prices are quoted in GB £, and are subject to Value Added Tax plus shipping

PLEASE NOTE: Some prices are not necessarily up to date, and may
be a lot less, so contact rosspeters@meridien.co.uk for the latest prices
 PART No.  DESCRIPTION  STOCK  RETAIL PRICE IN GB £
          9459   BATTERY BRACKET  001 16.68
          9468   MODIFIED RELAY 2.8  013  56.81
          9506   RUBBER SEALING STRIP  003  22.79
          9507   RUBBER SEALING STRIP  001  16.75
          9535   WATER RECIRCULATION KIT  001  263.33
          9552   V8 ALTERNATOR-AIR/CON KIT  001  1303.65
 100814070   SCREW  003  0.82
 101205008   SCREW  004  0.24
 101206012   SCREW  030  0.35
 101206016   SCREW  001  0.24
 101206020   SCREW  002  0.35
 101208018   SCREW  010  0.24
 101208020   BOLT  009  0.51
 101210020   BOLT  019  0.31
 108006014   SCREW  003  0.24
 108006030   SCREW  001  0.24
 108006055   SCREW 6X1X55  002  0.31
 108008035   OUTER SCREW  007  0.31
 108008045   SCREW  007  0.35
 108008055   BOLT  035  0.46
 108010025   HEXAGONAL SCREW / VITE AD ESAGONO  001  0.40
 108010055   SCREW  002  0.46
 108506016   BRAKE DISC SCREW  007  0.26
 108506020   BRAKE DISC BOLT  006  0.50
 112805020   SCREW  028  0.24
 112805025   SCREW  002  0.24
 112806014   SCREW  003  0.40
 113106014   BOLT  008  0.26
 119142130   SCREW  020  0.26
 119148130   SCREW  057  0.26
 119148160   SCREW  002  0.26
 119148220   SCREW  100  0.28
 119942190   SCREW  015  0.18
 122600050   NUT  003  0.24
 122750060   NUT  004  0.52
 125100100   NUT  004  0.35
 125400140   NUT  001  0.97
 128200080   ROD FIXING NUT  002  0.82
 128300060   NUT  012  0.47
 128310100   NUT  001  0.52
 128350060   SELF LOCKING NUT  007  1.07
 128350120   SELF LOCKING NUT  002  1.07
 128360140   SELF LOCKING NUT  006  1.34
 136110055   WASHER  038  0.26
 138200100   SPRING WASHER  100  0.24
 138200120   SPRING WASHER  002  0.31
 14440727   SCREW  006  0.24
 14456880   RUBBER GASKET  002  0.31
 14458980   RUBBER RING  023  0.94
 14778410   SCREW  003  0.40
 151700620   CIRCLIP  001  0.55
 163010060   WASHER  002  0.21
 163030060   WASHER  006  0.31
 164353075   RIVET  010  0.28
 178100200   TORQUE CONVERTOR DISC  001  33.17
 186404087   HOSE  007  2.14
 190400351   OIL SEAL  002  4.26
 192415330   SEALING GASKET  007  0.31
 30301124   TEMPERATURE SWITCH  001  16.66
 30311111   PARCEL COVER GREY  001  24.80
 30331131   SWITCH  005  15.50
 30331137   RELAY  004  4.89
 30331157   HANDBRAKE SWITCH  003  10.72
 30331161   IGNITION RELAY  001  10.72
 30471104   LOCK  002  21.45
 30471311   GAS SPRING PIN  038  4.76
 30551347   SPRING  012  0.54
 30811310   'Y' CONNECTION  003  1.94
 310232040   TUBING KIT  001  43.80
 310420303   SUMP DRAIN PLUG  002  4.76
 310420310   CLIP  001  1.78
 310420312   OIL EXHAUST TUBE  002  4.16
 310420331   DOWEL BETWEEN BLOCKS  007  2.95
 310420338   CYLINDER HEAD STUD  004  3.39
 310453341   'O' RING  001  2.01
 310620005   VALVE GUIDE  003  3.82
 310620314   RETAINING RING  001  0.02
 310620316   BARRELS CYLINDER  002  89.13
 310620353   RUBBER  285  4.09
 310620354   FILTER  005  1.31
 310620356   OUTER VALVE SPRING  158  3.02
 310620358   INNER EXHAUST VALVE  005  1.94
 310620361   LOWER VALVE SPRING RETAINER  004  0.67
 310620365   DOWEL  001  2.83
 310620372   WASHER  059  1.41
 310620450   VALVE  008  26.14
 310620451   INLET VALVE  015  16.14
 310620454   VALVE COLLET  081  0.60
 310625318   LINER  007  87.79
 310653010   INLET VALVE GUIDE  012  4.36
 310653457   LH 4V CAM HOUSING END PLATE  001  151.46
 310820004   CONNECTING ROD ASSEMBLY  006  164.20
 311020302   R.H.CAMSHAFT PULLEY  002  43.56
 311020310   DOWEL  001  1.14
 311020313   CAMSHAFT STOP PLATE  003  4.76
 311020314   WASHER  002  12.06
 311020325   INLET COLLAR TOP  004  19.44
 311020336   BUSH  006  0.50
 311020361   REGISTER SPRING  002  8.62
 311020364   BRACKET CHAIN TIGHTENER  002  20.11
 311020368   OIL SEAL  003  20.78
 311030108   CRANKSHAFT PULLEY  001  117.28
 311032005   TENSIONER KIT  002  182.62
 311053402   CAMSHAFT DOWEL  002  2.48
 311053410   OIL PIPE RH  001  12.06
 311053411   OIL PIPE LH  001  12.06
 311225004   PISTON WITH RINGS  005  123.31
 311225005   PISTON  004  123.31
 311225103   OIL SCRAPER  005  12.06
 311320300   LOWER FRONT PANEL  003  24.8
 311353112   INNER WING RH  001  378.65
 311570151   CARPET  001  130.69
 311820004   OIL PUMP ASSEMBLY  003  369.27
 311820101   PLUG  004  18.77
 311820304   SEAL  007  0.80
 311820317   GASKET  013  1.07
 311820321   OIL PUMP COVER/COPERCHIO POMPA OLIO  002  46.24
 311820323   DRIVEN GEAR  001  16.75
 311820324   DRIVEN GEAR  007  25.47
 311832108   OIL DELIVERY PIPE  001  58.98
 311832109   OIL RETURN PIPE  006  58.98
 312020135   PIPE  004  65.01
 312020138   TURBO PIPE  004  20.78
 312020310   GASKET  029  0.40
 312020319   LH AIR PIPE  005  34.18
 312020320   RH AIR PIPE  014  34.18
 312020405   OIL OUTLET SLEEVE  030  14.07
 312020407   'T' PIECE  002  12.73
 312020421   LH TURBO SLEEVE  003  10.58
 312020480   UPPER SLEEVE  023  24.8
 312020481   LOWER SLEEVE  004  24.8
 312020491   SEAL RING  014  1.14
 312020493   LH FUEL MANIFOLD  005  83.77
 312020494   RH FUEL MANIFOLD  005  83.77
 312020511   HOSE  001  7.01
 312021476   RH LOWER AIR PIPE  002  35.52
 312120300   BUFFER  012  1.14
 312220009   ASSEMBLY PLATE  001  10.72
 312220101   THROTTLE VALVE BODY  001  242.41
 312220312   SPRING  020  0.31
 312220414   PIPE CONNECTION  002  5.57
 312220477   AIR CONVEYOR  001  91.81
 312420107   CLAMP  001  2.75
 312420311   LH AIR PIPE  002  38.20
 312420330   LH SLEEVE  003  12.06
 312420334   RH CHROME PIPE  001  38.87
 312425003   UPPER COVER  002  26.81
 312520113   LH DOOR PILLAR  001  91.15
 312520114   RH DOOR PILLAR  001  91.15
 312520128   RHR BODY PANEL  001  12.73
 312520144   OPENING DEVICE  002  11.39
 312520307   REINFORCE FOR PANEL  001  26.14
 312520308   REINFORCE FOR PANEL  001  26.14
 312520377   LH REAR FENDER  001  237.92
 312520504   TRIM CLIP  050  0.47
 312520506   RH MUDGUARD  003  25.47
 312552529   SEAL  006  0.31
 312720121   RUBBER SUPPORT  002  14.80
 313020113   CHECK INSTRUMENT WIRING  001  20.77
 313020121   INSULATED WIRE  001  36.86
 313020331   FUSE BOX GUARD  001  8.04
 313030301   BLOCK  002  3.62
 313050422   SPACER FOR PULLEY  013  5.43
 313053132   LAMP WIRING LOOM  006  15.41
 313054125   WIRING LOOM  001  66.35
 313120214   LH ACTUATOR  001  91.82
 313120215   RH ACTUATOR  001  91.82
 313120309   RUBBER PAD  005  0.54
 313120405   BULB HOLDER  001  4.02
 313127321   COVER  002  1.41
 313130137   FRONT HEADLAMP  001  144.76
 313130138   EXTERIOR SUPPORT  002  14.07
 313132144   LIGHT HOLDER  001  10.07
 313153125   FOG LAMP  001  167.55
 313155147   LAMP LOOM  002  8.04
 313171146   BULB HOLDER  002  6.23
 313220100   ELECTRONIC BOX  001  152.58
 313220408   BRACKET  004  2.08
 313320105   FAN BLADE SHROUD  004  214.05
 313320112   PARKING LIGHT SWITCH  001  8.71
 313320131   REVERSE LIGHT SWITCH  001  12.06
 313320146   AIR HORN COMPRESSOR  001  40.21
 313320161   FUEL PUMP RELAY  002  24.13
 313320164   PRESSURE SENSOR  007  74.39
 313320182   ACCELERATION SENSOR  006  83.77
 313321190   MOTORE SCHIENALE  002  105.89
 313327329   SPACER  001  1.41
 313330135   CRASH SWITCH  003  29.49
 313332131   AUTO. TRANS. STARTER SWITCH  001  63.08
 313350205   INTERUPTOR/INTERUTORE  004  22.94
 313352158   WIPER BLADE  006  13.60
 313367118   4V WIPER ARM  016  62.33
 313420300   SCREW  010  1.09
 313620116   CLOCK WIRING HARNESS  001  20.77
 313620201   SPEEDOMETER  003  285.90
 313620214   REV COUNTER  003  152.58
 313655106   START INHIBITOR SWITCH  008  86.45
 313671201   SPEEDO MPH (AUTO)  002  335.89
 313720101   IGNITION WIRING HARNESS  004  412.96
No 100814070
to
No 313720101		 No 313720105
to
No 318002113		 No 318020324
to
No 329127125		 No 329132123
to
No 374530390		 No 374530792
to
No 980000972
No 9446
to
No 216771		 No 217657
to
No 366602134		 No 367002366
to
No 479021302		 No 479021402
to
No 981335200
